Product Parameters and Process Specifications of Vertical Conical Stainless Steel Feed Mixer
This equipment is a precision stainless steel powder mixing device, It is specially designed to address the pain points of ordinary carbon steel mixers, such as easy rusting, high contamination risk and excessive material residue. Its typical core industrial specifications are as follows:
-
Material Standard: The parts in contact with materials are made of standard 304 stainless steel. as standard 304 stainless steel feed blender, acid and alkali resistant, corrosion resistant, Resistant to flushing and chemical disinfection.
-
Equipment Structure: Vertical conical structure, Small floor space occupation, Mainly featuring low energy consumption, Large-batch rough mixing.
-
Batch mixing capacity: Common specifications include 40kg/p,50kg/p,60kg/p,85kg/p,95kg/p,135kg/p.
-
Transmission and Powertrain: Equipped with a high-hardness tooth surface reducer or cycloidal pinwheel reducer, Standard-equipped industrial motors with pure copper windings.
-
Mixing uniformity: Coefficient of Variation CV ≤ 5% (High-precision model CV ≤ 3%), The mixing cycle is usually 3 to 8 minutes per batch.
-
Sealing and Discharging: The shaft end adopts a combination of mechanical seal and gas seal. The bottom is equipped with a butterfly valve or large access door for discharging materials, Achieve an extremely low residual volume.
Under typical batch capacities ranging from Commercial poultry feed mixer 40kg to 135kg, the specifications of each model are as follows:
| Model | Host Power (KW) | Blender Diameter (MM) | Volume (L) | Total Weight (KG) |
|---|---|---|---|---|
| LV50 | 3 | 550 | 120 | 40 |
| LV75 | 3 | 620 | 160 | 50 |
| LV100 | 3 | 680 | 200 | 60 |
| LV150 | 3 | 900 | 260 | 85 |
| LV200 | 3 | 1000 | 320 | 95 |
| LV300 | 4 | 1200 | 460 | 135 |
Core Selling Points and On-site Process Characteristics of Vertical Conical Stainless Steel Feed Mixer
-
3Forged from 04 stainless steel, Confront High Humidity, High Acid and Alkali Working Conditions: It is often necessary to add fish meal, strongly acidic medicines, fermented green forage or high-moisture molasses. The stainless steel body resists corrosion from moisture and additives, As an efficient Anti-corrosive blender for animal feed, the material can be thoroughly flushed by directly connecting a water pipe during material replacement.
-
High-precision shearing and mixing, Prevent additive deposition: Especially when preparing materials with an extremely small proportion of additives. The equipment adopts multi-layer fluidized tumbling through internal and external reverse spiral ribbons, Forcefully break up lumps, It boasts leading technology Industrial stainless steel powder blender.
-
Zero Pollution Sealed Bearings and Quick-Drain Bottom Valves: The bearing assembly is completely isolated from the main mixing tank, Prevent backflow contamination of lubricating oil, Prevent material dust from penetrating into the bearings. The discharge outlet features a high sealing tightness, Fast discharging, Minimize cross-contamination to the greatest extent.
Target Customers and Practical Application Scenarios of Vertical Conical Stainless Steel Feed Mixer
-
Processing of Special Aquatic Feeds: High protein requirements for aquatic feed, The uniformity requirements for high-fat substances and trace elements are extremely stringent, Moreover, high-moisture raw materials are widely adopted in the formula, Highly corrosive raw materials. as standard Horizontal stainless steel mixer for animal feed,This equipment is the core mixing unit on the stainless steel aquatic feed production line.
-
High-Precision Additive and Premix Production Line: Veterinary drug factory, Feed Additive Factory Specially used for stirring vitamins, Minerals, High-value fine powders such as amino acids.
-
Food Grade and Fermented Feed Mixing: For cases requiring the addition of fermentation bacterial liquid, Biological fermented feed with biological agents. As a high-grade unit of high-quality High uniformity mixer for aquafeed, Stainless steel can resist organic acids generated during fermentation, Prevent the growth of miscellaneous bacteria.
-
Seamless supporting integration of front-end and back-end: This stainless steel mixer serves as the core connection point of the automated workshop, The front end can be configured with a Chemical resistant agricultural powder mixing machine for feeding, The backend directly connects to** stainless steel feed pellet machines** for pollution-free pelletizing.
